Commodore 1581 Replica

£125.00

Out of stock

Email when stock available

SKU: commodore-1581 Category:

Commodore 1581 Replica



For sale is a Commodore 1581 Replica PCB which has been fully assembled and tested.

The PCB is a design by Corei64 which is based on the original board design, and is compatible with the original case.
Placement of the ports and switches are in the original locations.
The enhanced PCB also features a separate power supply section so you have the option of no longer needing to use the original Commodore 1541-II/1581 power supply. Once built, you can power this board from any  power supply that outputs between 7.5 and 25V DC.
Note: This separate power supply section is not populated on this board  but can be easily added on – you will need to source the components and solder them in.

The PCB has been fully assembled with new chips (Apart from the chips that are obsolete) and features:
  • Newer 27C256 EPROM i place of original
  • 62256 RAM chip in place of original
  • Firmware 318045-02
This has been fully tested on my Commodore 64 using a physical floppy drive as well as a Gotek drive.
Note: To use this on a modern 3.5 floppy drive you will need to modify the floppy drive and you will also need a 3.5″ to 1581 floppy adapter PCB (Which I will start selling shortly)
Included is only the fully assembled PCB.
This excludes any cables, power supply, case and drive.
A 3D case is available on the printables website



Weight 200 g
